Galaxy Series Decorative Street Light
₹
22,000–1,20,000
per pole (ex-works)
6m–14m
MS (Mild Steel)
IP65
160 km/h
Galaxy Series poles redefine modern urban streetscaping with aerodynamic tapered profiles that reduce wind drag by 18% compared to cylindrical alternatives. The single and double-arm variants serve highway medians, smart city corridors, and premium township entries. CCTV mounting brackets, Wi-Fi antenna provisions, and smart dimming conduit paths are factory-integrated — making Galaxy Series the definitive choice for smart city projects.
Applications
IS:2062 Compliant
2–4 Week Lead Time
PAN India Delivery
20+ Year Lifespan
Technical Specifications
| Pole Height | 6m, 7m, 8m, 10m, 12m, 14m |
| Material | MS IS:2062 Gr.A |
| Wall Thickness | 4mm (standard), 5mm (HD) |
| Base Plate | 350×350×12mm |
| Anchor Bolt | 4×M24×700mm |
| IP Rating | IP65 |
| Wind Speed | 160 km/h |
| Arm Projection | 1m–2m |
| Wattage Compatibility | 30W–400W LED |
| Finish | HDG + Powder Coat 80 microns |
| Weight (8m) | 88 kg |
Key Features
- Aerodynamic tapered profile — 18% lower wind drag
- Integrated CCTV/antenna mounting bracket
- Smart dimming conduit (pre-wired 4-core)
- Double-arm configuration for road median installation
- Electrostatically applied powder coat 80 microns
- Anti-rust zinc primer before topcoat
- Hot-dip galvanized flanged base
- Optional solar top-mount
Product FAQs
Yes. Galaxy series meets NHAI and PWD specifications for median lighting with dual-arm configuration, minimum 8m pole height, and high-mast compatibility up to 14m.
Yes. Galaxy poles have factory-integrated CCTV brackets at 5m and 7m heights with a separate cable conduit channel to keep surveillance wiring isolated from lighting cables.
