Trishul Decorative Street Light Pole
₹
18,000–85,000
per pole (ex-works)
3m–12m
GI (Galvanized Iron)
IP65
150 km/h
The Trishul series embodies classical Indian architectural heritage fused with modern structural engineering. Its three-arm crown design distributes luminous intensity symmetrically across pedestrian zones, achieving 15–25 lux uniformity for parks and promenades. Fabricated from 3.15mm wall-thickness GI pipe and hot-dip galvanized before powder coating, each pole withstands wind loads exceeding 150 km/h — meeting IS:2062 structural steel standards.
Applications
IS:2062 Compliant
2–4 Week Lead Time
PAN India Delivery
20+ Year Lifespan
Technical Specifications
| Pole Height | 3m, 4.5m, 6m, 7.5m, 9m, 12m |
| Material | GI IS:1239 / IS:3589 |
| Wall Thickness | 3.15mm (standard), 4mm (heavy duty) |
| Base Plate | 300×300×10mm |
| Anchor Bolt | 4×M20×600mm |
| IP Rating | IP65 |
| Wind Speed | 150 km/h (Basic Wind Zone V) |
| Arm Projection | 0.5m–1.5m |
| Wattage Compatibility | 18W–250W LED |
| Finish | Powder Coat 60–80 microns |
| Color Options | RAL custom |
| Weight (6m) | 52 kg |
Key Features
- Three-arm symmetrical bracket design for uniform light spread
- Hot-dip galvanized + dual powder coat for 20+ year lifespan
- IP65 waterproof junction box with 4-core cable routing
- Modular design — compatible with LED, CCFL, and solar fixtures
- Base plate 300×300mm with 4×M20 anchor bolt pattern
- Optional smart dimming conduit path
- Vibration-damped arm joints
- Anti-graffiti coating available
Product FAQs
Trishul poles are engineered for Wind Zone V (150 km/h) as per IS:875 Part-3. Custom heavy-duty versions for coastal areas with wind speeds up to 180 km/h are available.
Yes. The Trishul pole has an integrated top-mounting provision and hidden cable conduit for a 30–60W solar panel. The three-arm variant supports solar-LED hybrid configurations.
Standard foundation depth is 1.2m for 6m poles in normal soil. For coastal or sandy soil, a reinforced concrete foundation of 1.5m depth is recommended.
